Name | Nickel Alloy Seamless Tube |
Standard | ASTM B622, ASTM B167, ASTM B163, ASTM B444 |
Certification | IOS9001:2015, PED |
Outer diameter | 6.0-609.6mm |
Wall thickness | 0.5-45mm |
Material | Hastelloy B-2, C-276, C-22, C-4, G-3, G-30, G-35; Inconel 625, 600, 601, 718, 750, 690 Incoloy 800, 825, 840, 901, 925; Monel 400, K-500; Haynes 556 (The product names are the registered trademarks of their respective owners. The enumeration here is only to show that the product specifications meet the requirements of relevant standards.) |
Delivery time | Within 35 days after receiving deposit |
Payment term | T/T,L/C |
Supply ability | 3000tons per year |
Packing | Export standard package with polywood case or ISPM 15 stamped wooden case |
Information | Beside the normal executive syandard.we could alse make the tubes according to your own requirements,such as wall thickness tolerance,hardness,surface requirements and etc.by different technical requirements and production technology,try our best to satisfied your. |
DIN/EN | UNS No | International name | Component |
|
1 | 2.4060 | N02000 | Nickl200 | 99Ni-0.15Fe-0.2Mn-0.1Si-0.1Cu-0.1C |
2 | 2.4601 | N02201 | Nickl201 | 99Ni-0.15Fe-0.2Mn-0.1Si-0.1Cu-0.01C |
3 | 2.4050 | N02270 | Nickl270 | 99.9Ni-0.02Fe-0.001Mn-0.002Si-0.005Cu-0.01C |
4 | 1.4980 | S66286 | INCOLOY Alloy A286 | 25Ni-15Cr-1.5Mo-2Ti-1Mg-0.03C |
5 |
| N08367 | INCOLOY Alloy 25-6HN | 25Ni-20Cr-6.3MO-0.25Cu-0.2N-0.01P-0.05S-0.01C |
6 | 1.4529 | N08926 | INCOLOY Alloy 25-6Mo | 25Ni-20Cr-6.5Mo-1Cu-0.2N-1.0Mg-0.01P-0.005S-0.01C |
7 | 2.4460 | N08020 | INCOLOY Alloy 20 | 36Ni-21Cr-3.5Cu2.5Mo-1Mn-0.01C |
8 | 1.4563 | N08028 | INCOLOY Alloy 28 | 32Ni-27Cr-3.5Mo-1Cu-0.01C |
9 | 1.4886 | N08330 | INCOLOY Alloy 330 | 35Ni-18Cr-2Mg-1SI-0.03C |
10 | 1.4876 | N08800 | INCOLOY Alloy 800 | 32Ni-21Cr-0.3~1.2(Al+Ti)0.02C |
11 | 1.4876 | N08810 | INCOLOY Alloy 800H | 32Ni-21Cr-0.3~1.2(Al+Ti)0.08C |
12 | 2.4858 | N08825 | INCOLOY Alloy 825 | 42Ni-21Cr-3Mo-2Cu-0.8Ti-0.1AI-0.02C |
13 | 2.4816 | N06600 | Inconel Alloy 600 | 72Ni-151Cr-8Fr-0.2Cu-0.02C |
14 | 2.4851 | N06601 | Inconel Alloy 601 | 60Ni-22Cr-1.2Al-0.02C |
15 | 2.4856 | N06625 | Inconel Alloy 625 | 58Ni-21Cr-9Mo-3.5Nb-1CO-0.02C |
16 | 2.4856 | N06626 | Inconel Alloy 625LCF | 58Ni-21Cr-9Mo-3.5Nb-1CO-0.02C |
17 | 2.4606 | N06686 | Inconel Alloy 686 | 57Ni-21Cr-16Mo-4W-0.01C |
18 | 2.4642 | N06690 | Inconel Alloy 690 | 58Ni-30Cr-9Fe-0.2Cu-0.02C |
19 | 2.4668 | N07718 | Inconel Alloy 718 | 52Ni-19Cr-5Nb-3Mo-1Ti-0.6Al-0.02C |
20 | 2.4669 | N07750 | Inconel Alloy 750 | 70Ni-15Cr-6Fe-2.5Ti-0.06Al-1Nb-0.02C |
21 | 2.4360 | N04400 | MONEL 400 | 63Ni-32Cu-1Fe-0.1C |
22 | 2.4375 | N05500 | MONEL K-500 | 63Ni-30Cr-1Fe-3Al-0.6Ti-0.1C |
23 | 2.4819 | N10276 | Hastelloy C-276 | 57Ni-16Mo-16Cr-5Fe-4W-2.5Co-1Mn-0.35V-0.08Si-0.01C |
24 | 2.4610 | N06455 | Hastelloy C-4 | 65Ni-16Cr-16Mo-0.7Ti-3Fe-2Co-1Mn-0.08Si-0.01C |
25 | 2.4602 | N06022 | Hastelloy C-22 | 56Ni-22Cr-13Mo-3Fe-2.5Co-0.5Mn-0.35V-0.08Si-0.01C |
26 | 2.4675 | N06200 | Hastelloy C-2000 | 59Ni-23Cr-16Mo-1.6Cu-0.08Si-0.01C |
27 | 2.4665 | N06002 | Hastelloy X | 47Ni-22Cr-18Fe-9Mo-1.5Co-0.6W-0.1C-1mn-1Si-0.008B |
28 | 2.4617 | N10665 | Hastelloy B-2 | 69Ni-28Mo-0.5Cr-1.8Fe-3W-1.0Co-1.0Mn-0.01C |
29 | 2.4660 | N10675 | Hastelloy B-3 | 65Ni-28.5Mo-1.5Cr-1.5Fe-3W-3Co-3Mn-0.01C |
30 |
| N06030 | Hastelloy G-30 | 43Ni-30Cr-15Fe-5.5Mo-2.5W-5Co-2Cu-1.5Mn-0.03C |
31 |
| N06035 | Hastelloy G-35 | 58Ni-33Cr-8Mo-2Fe-0.6Si-0.3Cu-0.03C |
32 | 1.4562 | N08031 | Nicrofer hMo31 | 31Ni-27Cr-6.5Mo-1.2Cu-2mn-0.01C |
33 | 2.4605 | N06059 | Nicrofer hMo59 | 59Ni-23Cr-16Mo-1.0Fe-0.01C |
FQA
Q: Are you a manufacturer?
A: Yes , we are a manufacturer, We have own factory, which is located in JIANGSU,CHINA. We have a leading power in producing and exporting stainless steel.carbon steel, various nickel-based alloys etc. We promise that we are what you are looking for.
Q:Can we visit your factory ?
A:Warmly welcome once we have your schedule we will pick you up .
Q: Do you have quality control?
A: Yes, we have gained BV, SGS authentication.
Q: Can you arrange the shipment?
A: Sure, we have permanent freight forwarder who can gain the best price from most ship company and offer professional service.
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to quantity.
Q:How can we get the offer?
A:Please offer the specification of the product,such as material,size,shape,etc.So wecan give the best offer.
Q:Can we get the some samples?Any charges?
A:Yes,you can get available samples in our stock.Free for real samples,but customers need to pay the freight cost.
Q: How do you make our business long-term and good relationship ?
A:We keep good quality and competitive price to ensure our customers' benefit; We respect every customer as our friend and we sincerrly do business and make friends with them, no matter where they come from.
